High-Temperature Investment Casting Regenerative Rotary Kiln

High-Temperature Investment Casting Regenerative Rotary Kiln

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	Qingdao,Shandong,China
option:	YN-XPL-1.4*1.3

$17400- /Piece/Pieces

17400USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information
Other information

Product Attributes

Model No.: YN-XPL-1.4*1.3

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Energy Saving

Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Machinery Repair Shops, Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	wooden box
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1.Technical parameter

Product name	The high standard electric box roasting furnace
Model	unit	YN-XPL-1.4*1.3
Active furnace space	mm	(14001300700)
Throat size	mm	(580*580)
Rated working temperature	ºC	≤1200
Installed power	KW	150-180
The use of voltage		380V
Installation dimensions	mm	375023002600
Weight of equipment	T	6.0

Note: The equipment specifications and models can be customized according to customer requirements.

2.Product advantages

1. Casting Quality Advantage: High temperature control precision and excellent furnace temperature uniformity ensure uniform heating of the mold shell during the firing process, fully burning out the binder within the mold shell, resulting in higher mold strength and improved air permeability. This significantly reduces the incidence of defects such as pores, slag inclusions, and cold shuts during the casting process, thereby improving the casting yield rate. For example, using a trolley-type energy-saving gas-fired firing furnace for investment casting of automotive engine parts has reduced the casting scrap rate from 8%-12% with traditional equipment to 3%-5%. The dimensional accuracy of the castings has also been significantly improved, consistently reaching CT6-CT7 grades.

2. Production Efficiency Advantage: The trolley-type energy-saving gas-fired firing furnace features rapid heating, optimal heat retention, and intelligent cooling, effectively shortening the firing cycle for a single batch of mold shells. Furthermore, the rapid loading and unloading of the trolley and its cycle operation enable continuous production and improve equipment utilization. Compared with traditional gas-fired regenerative roasting furnaces, production efficiency can be increased by 30% - 50%, which can better meet the large-scale and high-efficiency production needs of modern foundries.

Supply Ability & Additional Information

Packaging: wooden box

Transportation: Ocean,Land

Supply Ability: 500piece/Year

Certificate: ISO 9001:2015

Port: Qingdao,Shandong,China

Payment Type: T/T

Incoterm: FOB,CIF,EXW
