Investment casting regenerative baking equipment

Investment casting regenerative baking equipment

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	qingdao
Model:	YN-XPL-1.4*1.3

$19120- /Piece/Pieces

19120USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information
Other information

Product Attributes

Model No.: YN-XPL-1.4*1.3

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Wooden box packaging
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1,Technical parameter

Product name	The high standard electric box roasting furnace
Model	unit	YN-XPL-1.4*1.3
Active furnace space	mm	(14001300700)
Throat size	mm	(580*580)
Rated working temperature	ºC	≤1200
Installed power	KW	150-180
The use of voltage		380V
Installation dimensions	mm	375023002600
Weight of equipment	T	6.0

Note: All equipment specifications and models are fully customizable to align with specific customer requirements.

2. Key Benefits & Features

2.1 High-volume load capability combined with superior heat treatment performance for oversized components, ensuring cost-efficient operation and enhanced productivity.

2.2 Advanced full-fiber lining design significantly boosts thermal insulation compared to conventional brick chambers, improving energy retention and process consistency.

2.3 Compact and mid-sized units feature integrated rail systems and require no foundation setup, enabling flexible deployment on any flat surface.

2.4 Multi-zone heating technology is standard in larger models, with heating elements strategically positioned on the door, rear wall, and bogie to achieve uniform temperature distribution. Each heating zone is managed by an independent automated control system for precision regulation.

2.5 Fully automated operation of the bogie and door mechanisms is standard. Every electrical cabinet includes digital instrumentation and a real-time monitoring system to ensure continuous process oversight and control.

Supply Ability & Additional Information

Packaging: Wooden box packaging

Transportation: Ocean,Land

Supply Ability: 120piece/Year

Certificate: ISO9001：2015

Port: qingdao

Payment Type: T/T

Incoterm: FOB,CIF,EXW
