Advanced Shell Making Manipulator Arm

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	Q
Model:	YN-JXS-4/8
option:	YN-JXS-4/8

$44120- /Piece/Pieces

44120USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-JXS-4/8

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Wooden box packaging
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1,technical parameter

Swing rotation speed	180 °/0-10 seconds (adjustable)
Lifting rotation speed	180 °/0-10 seconds (adjustable)
Center distance between two string shell moulds	500mm
Weight of single string shell mold	≤30kg
Equipment structure	Three arms and six hands
work efficiency	≥1 string/20-25s
Rotation angle of main column	0-360°(Continuous rotation)
Rotation index of main column	120°/3 stations
Rotation speed of main column	90 °/0-10s (adjustable)
Movement angle range of clamping module	-10 ° to 135 ° (centered on the vertical line of the ground plane)
Up and down (z-axis) stroke of station	0-700mm (adjustable)
Technical indicators	Technical parameter
Center distance between two string shell moulds	500mm
Self rotation speed of workpiece	5-40 rpm (adjustable)
Pick up mode	Manual hanging
Fixture mode	Pneumatic automatic locking
Quickly replace tooling	Quickly replace adaptive clamps according to different hooks

2,Benefit description

Introducing our premium Robot Arm for Shell Making, the perfect solution for automating the shell making process in industrial settings. This advanced manipulator is designed to streamline production and improve efficiency.

Key Features:

Highly precise movements for accurate shell making
Robust construction for long-lasting performance
Easy to program and operate
Flexible design to adapt to different shell sizes and shapes
Enhanced safety features to protect operator
Our Premium Industrial Arm for Shell Making is the ideal choice for manufacturers looking to optimize their production line. With its cutting-edge technology and reliable performance, this manipulator will revolutionize the way shells are made.Whether you are producing small or large shells, our Robot Arm for Shell Making can handle the task with ease. Its versatility and precision make it a valuable asset for any industrial setting.Experience the future of shell making with our premium manipulator. Upgrade your production line today and see the difference it makes!Users have praised the efficiency and accuracy of our Robot Arm for Shell Making. They have noted significant improvements in production speed and quality since implementing this advanced manipulator.

Frequently Asked Questions:

Is the Robot Arm for Shell Making easy to install?
Can the manipulator be customized for specific shell designs?
What safety features does the arm have to protect operators?
How does the arm improve efficiency in shell making?

Supply Ability & Additional Information

Packaging: Wooden box packaging

Productivity: 120piece/year

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 120piece/year

Certificate: ISO 9001:2015

Port: Q

Payment Type: T/T

Incoterm: FOB,CIF,EXW
