Efficient Mold Shell Dewaxing Unit

Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	QINGDAO
Model:	YN-DTF-1400Z
option:	YN-DTF-1400Z

$26180- /Piece/Pieces

26180USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-DTF-1400Z

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Spare Parts, Video Technical Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Other, Machinery Repair Shops, Manufacturing Plant

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	WOODEN BOX
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1.Main Features and Advantages

1. Efficient Dewaxing: Rapid heating allows for rapid reaching of the desired dewaxing temperature. Aeration and equilibration time are short, typically reaching a pressure of 0.6 MPa or higher within 5-10 seconds. This rapid dewaxing process effectively shortens production cycles.

2. Environmentally Friendly and Energy-Saving: Some dewaxing kettles utilize new insulation materials with low thermal conductivity and excellent insulation properties, reducing fuel consumption. They may also be equipped with energy recovery devices to improve energy recovery efficiency, reduce waste generation, and meet environmental standards.

3. Safe and Reliable: Multiple safety features are included, including dual pressure and temperature control, and mechanical interlocking and interlocking of the aeration valve and kettle door. The door cannot be opened if the kettle is pressurized, and air cannot be supplied unless the door is fully closed, ensuring operator safety.

4. Easy Operation: Highly automated, with features such as automatic water replenishment and dewaxing timer. Optionally, these kettles can be equipped with automatic mold entry and exit devices and automatic door opening mechanisms, reducing labor intensity and improving production efficiency.

5. Wax-water separation and filtration: Equipped with wax-water separation capabilities, the melted wax undergoes double filtration, yielding a high-purity wax material that can be reused, improving wax utilization and reducing production costs.

6. High equipment stability: The kettle body typically utilizes a double-layer high-pressure vessel made of specialized boiler material and reinforced with thickened steel plates, extending the equipment's service life and ensuring overall stability, meeting the requirements of long-term continuous production.

2.technical parameter

Model	YN-DTF-1400Z
working space	φ1400×1600mm
working pressure	0.85MPa
working temperature	185ºC
Design pressure	0.95MPa
Voltage regulating range	0~0.85MPa
Boost rate	0.6MPa/5s
power	380V/50Hz 243kw

Supply Ability & Additional Information

Packaging: WOODEN BOX

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 120PCS/YEAR

Certificate: ISO 9001:2015

Port: QINGDAO

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF,EXW
