Smart Robotic Arm System for Shell Casting Safety

Smart Robotic Arm System for Shell Casting Safety

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	Q,i,n

$38240- /Piece/Pieces

38240USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-JXS-6/3

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Spare Parts, Online Support, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Other, Manufacturing Plant

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	wooden box
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

Product Description

1.Technical parameter

Self rotation angle of workpiece	360 ° (continuous rotation)
Rotation speed of main column	90 °/0-10s (adjustable)
Weight of single string shell mold	≤30kg
Equipment structure	Three arms and six hands
work efficiency	≥1 string/20-25s
Rotation angle of main column	0-360°(Continuous rotation)
Rotation index of main column	120°/3 stations
Technical indicators	Technical parameter
Movement angle range of clamping module	-10 ° to 135 ° (centered on the vertical line of the ground plane)
Up and down (z-axis) stroke of station	0-700mm (adjustable)
Lifting rotation speed	180 °/0-10 seconds (adjustable)
Swing rotation speed	180 °/0-10 seconds (adjustable)
Center distance between two string shell moulds	Center distance between two
Outline dimension of single string shell mold	$450mmXH500mm
Pick up mode	Manual hanging
Fixture mode	Pneumatic automatic locking
Weight of single string shell mold	≤30kg

2.Benefit description

High-End Robotic Arm Guarantees Secure Shell Casting

This precision casting robotic arm setup is engineered to deliver high-precision management for precision casting, ensuring both safe and efficient production workflows.

By leveraging state-of-the-art robotic tech, the system provides automated manufacturing functions and high-precision regulation to achieve top-tier performance.

Core Traits:

• Cutting-edge robotic arm engineering

• Secure and streamlined shell casting

• Automated production capacities

• High-precision control for steady outcomes

Detailed Overview:

The sophisticated technology integrated into this robotic arm system optimizes the shell casting workflow, lowering accident risks and boosting overall operational efficiency.

Its high-precision control allows for accurate movements and consistent results, making it a must-have tool for manufacturers aiming to produce high-quality goods.

Usage Scenarios:

Perfect for sectors needing advanced shell casting automation, including automotive, aerospace, and mechanical manufacturing fields.

It can be applied in diverse production settings to enhance safety levels and productivity rates.

In summary, this precision casting robotic arm system serves as a dependable and efficient solution for manufacturers seeking to upgrade their shell casting procedures.

Supply Ability & Additional Information

Packaging: wooden box

Productivity: 120piece/year

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 120piece/year

Certificate: ISO 9001:2015

Port: Q,i,n

Payment Type: T/T

Incoterm: FOB,CIF,EXW
