Model No.: YN-JXS-6/3
Brand: Enon
Place Of Origin: China
Old And New: New
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: New Product 2020
Core Component Warranty Period: 1 Year
Core Components: Plc
Warranty Period: 1 Year
Core Selling Point: Easy To Operate
Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
Applicable Industry: Other, Manufacturing Plant
| Selling Units: | Piece/Pieces |
| Package Type: | wooden box |
| Picture Example: |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Pick up mode | Manual hanging |
| Fixture mode | Pneumatic automatic locking |
| Center distance between two string shell moulds | 500mm |
| Weight of single string shell mold | ≤30kg |
| Equipment structure | Three arms and six hands |
| work efficiency | ≥1 string/20-25s |
| Rotation angle of main column | 0-360°(Continuous rotation) |
| Rotation index of main column | 120°/3 stations |
| Rotation speed of main column | 90 °/0-10s (adjustable) |
| Movement angle range of clamping module | -10 ° to 135 ° (centered on the vertical line of the ground plane) |
| Up and down (z-axis) stroke of station | 0-700mm (adjustable) |
| Lifting rotation speed | 180 °/0-10 seconds (adjustable) |
| Swing rotation speed | 180 °/0-10 seconds (adjustable) |
| Self rotation angle of workpiece | 360 ° (continuous rotation) |
| Self rotation speed of workpiece | 5-40 rpm (adjustable) |
| Technical indicators
| Technical parameter |
| Center distance between two string shell moulds | Center distance between two |
| Quickly replace tooling | Quickly replace adaptive clamps according to different hooks |
High-Performance Precision Shell Arm
The High-Performance Precision Shell Arm is a cutting-edge pneumatic arm designed for precision shell handling, enhancing your production process. This innovative arm provides unparalleled efficiency and precision in shell handling tasks.
Key Features:
Precision control for delicate shell handling
Efficient pneumatic system for fast and reliable operation
Durable shell arm construction for long-lasting performance
Adjustable settings for a variety of shell sizes and shapes
Easy integration into existing production lines
The High-Performance Precision Shell Arm is ideal for seafood processing plants, streamlining shell handling processes and improving overall productivity. Its advanced technology ensures consistent results and reduces the risk of error.
Applications:
The High-Performance Precision Shell Arm is ideal for oyster shucking, clam processing, and other shell-related tasks in food industry environments. It can also be used in research laboratories for precise shell handling.
User Reviews:
"This arm has completely revolutionized our shell handling process. It's fast, accurate, and easy to use." - John S.
"I highly recommend the High-Performance Precision Shell Arm to anyone who needs efficient shell handling equipment." - Sarah L.
Q: Is this arm easy to install? A: Yes, this arm can be easily integrated into existing production lines.
Packaging: wooden box
Productivity: 120piece/year
Transportation: Ocean,Land
Place of Origin: China
Supply Ability: 120piece/year
Certificate: ISO 9001:2015
Port: Q,i,n
Payment Type: T/T
Incoterm: FOB,CIF,EXW
