Open wax injection machine for lost wax casting

Open wax injection machine for lost wax casting

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Transportation:	Ocean,Land
Port:	青岛
option:

$208501-2 Piece/Pieces
$207503-4 Piece/Pieces
$20600≥5 Piece/Pieces

$ 20600 - 20850 / Piece/Pieces

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-DMZ-16LB-Y

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Wooden box packaging
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1. Technical parameters

Specifications and models	YN-DMZ-16LB-Y	YN-DMZ-20LB-Y	YN-DMZ-25LB-Y
Mold clamping force	16T	20T	25T
Mold usage space (Depth×Width ×Height)	520×570×600mm	550×610×600mm	650650600
Pressure plate form	Four-column guide	Four-column guide	Four-column guide
Mold clamping stroke (A)	500mm	500mm	700mm
Maximum opening distance (B)	600mm	600mm	600mm
Minimum opening distance (C)	100mm	100mm	100mm
Pneumatic core pulling	4 groups start core pulling	4 groups start core pulling	4 groups start core pulling
Maximum amount of wax injected in one time (wax cylinder)	5L	5L	7.5L

2. Product Description

1. Wax injection pressure adjustment is available in two levels: pressure control and manual adjustment.

2. Nozzle advance and retraction are controlled by a hydraulic system, while nozzle lift and lowering are driven by a motor.

3. The wax storage tank is equipped with a temperature overload protection device, providing dual protection.

4. The wax storage tank is equipped with an automatic liquid level control device, allowing the wax melter to automatically supply wax. When the wax level reaches the upper limit, the wax supply automatically stops. Operation modes include automatic and manual wax replenishment.

5. Temperature Control Zones: Each left and right station features a wax storage tank, a cooling tank, a wax extrusion tank, and a wax injection nozzle, for a total of five temperature zones. The wax storage temperature ranges from 70-90°C to 55-60°C.

6. This intelligent Wax Injection Machine features a 10-inch full-color LCD touchscreen and a Siemens PLC control system. All parameter settings (including temperature, time, core pulling, core insertion, etc.) are directly displayed. The user interface is simple and elegant, and operation is easy.

7. This wax injection machine is a single-station, four-column vertical template machine. Hydraulic mold clamping and thermal oil heating as insulation ensure a stable, safe, and reliable operating system.

8. Operation: Manually activated to prevent accidental hand pinching, with a safety light at the foot. Mold clamping stops upon contact with the guardrail to prevent pinching injuries.

9. The hydraulic system's output flow and pressure are controlled by a Y-type motor and can be manually adjusted.

10. Equipped with an ejector pin, the system can be designed to automatically eject the mold, allowing for quick and easy wax pattern removal.

Supply Ability & Additional Information

Packaging: Wooden box packaging

Transportation: Ocean,Land

Supply Ability: 5 Set/Sets Per Month

Certificate: ISO 9001:2015

Port: 青岛

Payment Type: T/T

Incoterm: FOB,CIF,EXW
