Model No.: YN-HPL-1.6x1.8
Brand: Enon
Place Of Origin: China
Old And New: New
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: New Product 2020
Core Component Warranty Period: 1 Year
Core Components: Plc
Warranty Period: 1 Year
Core Selling Point: Easy To Operate
Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
Applicable Industry: Manufacturing Plant, Other
| Selling Units: | Piece/Pieces |
| Package Type: | wooden box |
| Picture Example: |
|
The file is encrypted. Please fill in the following information to continue accessing it
| Model | YN-HPL-1.6x1.8 |
| Power | 3X380V 50HZ |
| Power (KW) | 8.5 |
| Bottom plate of furnace door (mm) | ≥8mm |
| Outer diameter of furnace door rolling rod (mm) | ≥38 |
| Weight (T) | 1800 |
| Smoke exhaust temperature (mm) | ≤100ºC |
| Thickness of furnace guard plate (mm) | ≥ 4 (fixed with channel steel inside) |
| Thickness of furnace surface protection plate (mm) | ≥6 |
| Ignition method | High voltage pulse (automatic) |
| Fuel | Natural gas |
| Furnace door lifting motor | 1.5KW |
| Combustion fan | 3.0KW |
| Smoke exhaust fan | 4.0KW |
| Combustion fan air volume | Frequency converter adjustment |
| Smoke exhaust fan air volume | Frequency converter adjustment |
| Wind and natural gas (ignition process) | Quantitative control |
| Furnace nozzle gas inlet pressure (Kap) | 7~8 |
| Hourly flow rate of gas pipeline | 35-40 cubic meters |
| Preheating air temperature | 150~250ºC |
| Design maximum temperature | 1300ºC |
| Long term operating temperature | ≤1200ºC |
| Thickness of furnace wall steel plate | 4mm |
Packaging: wooden box
Transportation: Ocean,Land
Supply Ability: 500piece/Year
Certificate: ISO 9001:2015
Port: Qingdao,Shandong,China
Payment Type: T/T
Incoterm: FOB,CIF,EXW
