Three head six arm robot

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	Qingdao
Model:	YN-JXS-6/3
option:

$38240- /Piece/Pieces

38240USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-JXS-6/3

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Spare Parts, Online Support, Video Technical Support, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Other, Manufacturing Plant

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	wooden box
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1.Benefit description

Introducing our latest innovation in industrial automation - the Precision Industrial Robot Arm with Six Hands. This cutting-edge industrial manipulator features three arms with six hands, providing unmatched precision and efficiency in shell fabrication.

Key Features:

This cutting-edge industrial manipulator features three arms with six hands, providing unmatched precision and efficiency in shell fabrication. Key Features: - Three arms, six arms for increased flexibility and productivity - Precision engineering ensures high accuracy and repeatability - Designed specifically for housing manufacturing, delivering exceptional performance - Advanced technology for seamless integration with existing systems - Rugged, durable, and reliable construction This precision six-arm industrial robot is suitable for a wide range of applications, including housing manufacturing, assembly, and pick-and-place tasks. Its versatility and efficiency make it a valuable asset in any industrial environment.

Precision engineering ensures high accuracy and repeatability

Designed specifically for housing manufacturing, delivering exceptional performance

Advanced technology for seamless integration with existing systems

Rugged, durable, and reliable construction

This precision six-arm industrial robot is suitable for a wide range of applications, including housing manufacturing, assembly, and pick-and-place tasks. Its versatility and efficiency make it a valuable asset in any industrial environment.

2.Technical parameter

Technical indicators	Technical parameter
Outline dimension of single string shell mold	$450mmXH500mm
Center distance between two string shell moulds	500mm
Weight of single string shell mold	≤30kg
Equipment structure	Three arms and six hands
work efficiency	≥1 string/20-25s
Rotation angle of main column	0-360°(Continuous rotation)
Rotation index of main column	120°/3 stations
Rotation speed of main column	90 °/0-10s (adjustable)
Movement angle range of clamping module	-10 ° to 135 ° (centered on the vertical line of the ground plane)
Up and down (z-axis) stroke of station	0-700mm (adjustable)
Lifting rotation speed	180 °/0-10 seconds (adjustable)
Swing rotation speed	180 °/0-10 seconds (adjustable)
Self rotation angle of workpiece	360 ° (continuous rotation)
Self rotation speed of workpiece	5-40 rpm (adjustable)
Pick up mode	Manual hanging
Fixture mode	Pneumatic automatic locking
Quickly replace tooling	Quickly replace adaptive clamps according to different hooks

Sanding Process: After the slurry dripping is complete, the robotic arm continues to rotate to the sanding station. Here, the sanding device begins operating, evenly spraying sand onto the formwork surface. The robotic arm precisely controls the formwork's rotation speed and angle to ensure the sand is evenly applied to the formwork surface, forming a dense sand shell and enhancing its strength and stability.

Completion and Unloading: After the above steps, the formwork is complete. The robotic arm rotates the formwork back to the loading and unloading station, where a worker removes the formwork and hangs it on the drying line. Alternatively, an auxiliary robotic arm automatically removes the formwork and hangs it back on the drying line. The robotic arm then resumes its work cycle.

Supply Ability & Additional Information

Packaging: wooden box

Productivity: 120piece/year

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 120piece/year

Certificate: ISO 9001:2015

Port: Qingdao

Payment Type: T/T

Incoterm: FOB,CIF,EXW
