Casting low temperature double-station wax injection machine

Casting low temperature double-station wax injection machine

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	qingdao
Model:	YN-DZJ-140S

$12940- /Piece/Pieces

12940USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-DZJ-140S

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Wooden box packaging
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1,Technical parameter

Illustrate	YN-DZJ-140S
Wax injection pressure	MPa	0.4-0.8
Wax tank volume	L	140
Motor power	kw	2.2
Temperature control range	ºC	30-80
Heating power	KW	2X3KW
Power conditions		3-phase/380V/50Hz

Main structural features:
1. An essential equipment for low-temperature wax pattern making in the investment casting industry. It is suitable for water glass technology and is an ideal equipment for low-temperature wax pattern making.
2. Equipped with a pressure control device and a heating control device, the pressure and temperature of the wax cylinder are automatically adjusted so that the wax material is always in the ideal wax paste state, making it easy to produce ideal models.
3. The wax tank has large volume and high efficiency, making it easy to manufacture large models and easy to use.
4. The dual-jet wax guns are relatively independent and do not affect each other. They can be operated simultaneously or separately. The air system adopts domestically advanced manual reversing valve oil and gas filtration devices and plug-in quick connectors, which are easy to install, easy to change tubes, and sealed. Reliable, strong and beautiful connection, long life
5. Equipped with a micro silencer and a flow regulating valve, the noise is low and the flow rate is adjustable to achieve the purpose of adjusting and controlling the operating speed.
6. The wax injection head is manually controlled, easy to operate, flexible and equipped with a stirring device, making the mold material more uniform and easier to use.

Supply Ability & Additional Information

Packaging: Wooden box packaging

Transportation: Ocean,Land

Supply Ability: 120piece/Year

Certificate: ISO 9001:2015

Port: qingdao

Payment Type: T/T

Incoterm: FOB,CIF,EXW
