Double-station investment casting wax paste making machine

Double-station investment casting wax paste making machine

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	qingdao
Model:	YN-ZGJ-140*2

$12940- /Piece/Pieces

12940USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-ZGJ-140*2

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Wooden box packaging
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1,Technical Parameters

Model	YN-ZGJ-140*2
Volume of wax box	140 L
Blade spee	950 r/min (adjustable with variable frequency)
Power	2.2kw
Drum speed	14 r/min

2,Main feature

1. Heating utilizes automatic temperature control, set by a temperature controller. When the temperature reaches the set value, a signal is transmitted to the temperature sensor via a temperature sensor.

The temperature controller automatically cuts off the heater power supply and automatically restarts the heater when the temperature drops.

2. The heating belt is equipped with a rotary temperature control knob. When the temperature continues to rise to a certain value, the heating power supply is cut off to prevent accidents.

3. The paste-making system uses cold water and variable frequency speed regulation to control the wax paste hardness and paste-making speed.

4. This equipment primarily consists of the following components:

Wax liquid storage tank: for storing liquid wax raw materials;

Paste roller: for forming the wax paste;

Wax paste mixing drum (two): for mixing and stirring the wax paste to ensure uniformity;

Water cooling system: provides cooling and optimizes the wax paste curing process;

Wax delivery system: for automated delivery of liquid and paste wax. Tank Structure:

Inner tank: Welded from 304 stainless steel plates, ensuring corrosion resistance and sanitation.

Intermediate heating layer: Welded from 2mm thick stainless steel plates, with a built-in independent electric heater, using water as the heat transfer medium for uniform heating.

Insulation: The outer layer utilizes rock wool insulation to effectively reduce heat loss, prevent surface burns, and enhance operational safety.

This design combines efficient heating with temperature stability, making it ideal for producing high-quality wax pastes.

Supply Ability & Additional Information

Packaging: Wooden box packaging

Transportation: Ocean,Land

Supply Ability: 120piece/year

Certificate: ISO 9001:2015

Port: qingdao

Payment Type: T/T

Incoterm: FOB,CIF,EXW
