Safe and reliable steam dewaxing pot

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Land,Ocean
Port:	qingdao
Model:	YN-DTF-1000Z

$15880- /Piece/Pieces

15880USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information
Other information

Product Attributes

Model No.: YN-DTF-1000Z

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	Wooden box packaging
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1,technical parameter

Model	YN-DTF-1000Z
working space	φ1000×1100mm
working pressure	0.85MPa
working temperature	185ºC
Design pressure	0.95MPa
Voltage regulating range	0~0.85MPa
Boost rate	0.6MPa/5s
power	380V/50Hz 123kw
dimensions	3250×1740×2150
weight	2.75T

DTF Electric Steam Dewaxing Kettle is a key component of the precision Casting Equipment lineup manufactured by our company. It is specifically designed for the dewaxing of mold shells in precision casting processes. Integrating the strengths of both domestic and international counterparts, this dewaxing kettle prioritizes safety, reliability, and practicality while delivering rapid heating and efficient dewaxing performance. It stands as an ideal solution that combines high thermal efficiency with excellent environmental performance.

Main Features and Advantages:

1. Double-Layer Pressure Vessel Design: The DTF electric steam dewaxing kettle features a double-layer structure. During operation, the outer tank maintains high temperature and pressure, ensuring the inner surface temperature remains consistently above 150°C. This design eliminates condensate accumulation in the inner tank, promotes rapid thermal equilibrium, reduces steam consumption during dewaxing, minimizes shell cracking, and results in lower moisture content in the reclaimed wax.

2. Robust Construction: The dewaxing kettle consists of a tank body, base, quick-opening door, wax collection tank, heating elements, electrical control cabinet, and exterior cladding. It is also equipped with a transport cart and mold baskets to facilitate smooth and efficient dewaxing operations.

3. Enhanced Safety and Operability: The quick-opening door mechanism ensures both safety and convenience, allowing for fast and easy access. A safety interlock system prevents the door from being opened unless the pressure release valve is activated, significantly enhancing operational safety. The unit also includes adjustable pressure settings, allowing users to select their desired working pressure within the design limits.

4. Comprehensive Protection Systems: The equipment is fitted with multiple safety features, including low-water-level protection that halts heating when water levels are insufficient to prevent dry firing and element damage. An over-temperature alarm and automatic shutdown provide additional protection. Other standard fittings include safety valves, intake and exhaust valves, a wax discharge valve, drain valve, check valve, pipeline filter, pressure gauge, and temperature indicator.

Supply Ability & Additional Information

Packaging: Wooden box packaging

Transportation: Land,Ocean

Supply Ability: 120piece

Certificate: ISO9001:2015

Port: qingdao

Payment Type: T/T

Incoterm: FOB,CIF,EXW
