Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine
Fast Temperature Rise Dewaxing Machine

Fast Temperature Rise Dewaxing Machine

Payment Type:T/T
Incoterm:FOB,CIF,EXW
Min. Order:1 Piece/Pieces
Transportation:Ocean,Land
Port:QINGDAO
Model:
  • YN-DTF-1200Z
  • $23240- /Piece/Pieces

23240USD

  • Product Attributes
  • Packaging & Delivery
  • Product Description
  • Supply Ability & Additional Information
Product Attributes

Model No.YN-DTF-1200Z

BrandEnon

Place Of OriginChina

Old And NewNew

Video Factory InspectionProvided

Mechanical Test ReportProvided

Marketing TypeNew Product 2020

Core Component Warranty Period1 Year

Core ComponentsPlc

Warranty Period1 Year

Core Selling PointEasy To Operate

Out-of-warranty ServiceVideo Technical Support, Spare Parts, Online Support, Field Maintenance And Repair Service

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets)None

Showroom Location (in Which Countries Are There Sample Rooms Overseas)None

Applicable IndustryManufacturing Plant, Other

Packaging & Delivery
Selling Units: Piece/Pieces
Package Type: WOODEN BOX
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

Fast Temperature Rise Rapid Dewaxing Investment Casting Foundry Dewaxing Machine Sale

2. This equipment consists of seven components: the furnace body, kettle, kettle door, water supply system, valve system, heating system, and electronic control system. The stainless steel shell and head are all made of boiler-grade stainless steel. The double-layer wax drain pipe and wax receiving trough are also made of stainless steel. All materials comply with the national "Pressure Vessel Inspection Standards." Each unit comes with two sets of trolleys and material baskets for loading the mold shells.
The kettle body is a double-chamber design, and the kettle door features a gear ring structure. The inner tank is made of 345R and the outer tank is made of Q235B.
The internal pressure control of the furnace utilizes an advanced pressure transmitter and three-stage pressure control, achieving fully automatic pressure increase and maintaining operating pressure at half power. Closed-circuit pressure control is used within the kettle, providing full-process variable pressure control, enabling rapid pressure increase with large pressure differentials, low-pressure exhaust, and pressure-limited wax drain. Air intake, exhaust, and wax drain are all completed with a single button, effectively preventing shell cracking and significantly reducing energy consumption.
1,technical parameter
Model YN-DTF-1200Z
working space φ1200×1500mm
working pressure 0.85MPa
working temperature 185ºC
Design pressure 0.95MPa
Voltage regulating range 0~0.85MPa
Boost rate 0.6MPa/5s
power 380V/50Hz 153kw
dimensions 4250×2050×2150
weight 4.2T

3. Comprehensive Safety Protection
Recognizing that safety is the cornerstone of production, the electric steam dewaxing kettle is equipped with comprehensive safety protection mechanisms. Mechanical pressure protection acts as a sturdy shield, ensuring that furnace pressure always remains within a safe range. Electronic pressure protection uses intelligent monitoring to instantly cut off power if pressure exceeds the set range, preventing potential hazards before they occur. Temperature-controlled indirect pressure protection cleverly monitors pressure indirectly through temperature changes, providing an additional layer of safety. When the water level falls below the set value, a water shortage alarm sounds, simultaneously shutting off power to the heater to prevent dry-burning. An overtemperature alarm sounds if the temperature rises abnormally, protecting the equipment from high-temperature damage. A process time alarm thoughtfully alerts the operator when the process time has expired, ensuring precise control of the production process. Furthermore, a safety valve automatically opens in the event of abnormal pressure, providing a final line of defense for equipment safety.The electric steam dewaxing kettle, with its comprehensive safety features, intelligent water level management, rugged design, precise pressure control, and convenient operation, has become a leader in the industrial dewaxing field. It not only improves production efficiency and reduces energy consumption, but also ensures a safe and reliable production process. Whether in the high-end aerospace industry or the more practical craft production industry, the electric steam dewaxing kettle, with its superior performance and thoughtful design, provides users with efficient, safe, and energy-saving dewaxing solutions, helping various industries move towards a higher-quality production future.

Supply Ability & Additional Information

PackagingWOODEN BOX

TransportationOcean,Land

Place of OriginChina

Supply Ability120PCS/YEAR

CertificateISO 9001:2015

PortQINGDAO

Payment TypeT/T

IncotermFOB,CIF,EXW
