Efficient High Pressure Dewaxing Kettle

Payment Type:	T/T
Incoterm:	FOB,CIF,EXW
Min. Order:	1 Piece/Pieces
Transportation:	Ocean,Land
Port:	QINGDAO
Model:	YN-DTF-1200Z

$23240- /Piece/Pieces

23240USD

Contact Now

Product Attributes
Packaging & Delivery
Product Description
Supply Ability & Additional Information

Product Attributes

Model No.: YN-DTF-1200Z

Brand: Enon

Place Of Origin: China

Old And New: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Core Components: Plc

Warranty Period: 1 Year

Core Selling Point: Easy To Operate

Out-of-warranty Service: Spare Parts, Video Technical Support, Field Maintenance And Repair Service, Online Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Applicable Industry: Manufacturing Plant, Other

Packaging & Delivery

Selling Units:	Piece/Pieces
Package Type:	WOODEN BOX
Picture Example:

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

1,Technical parameter

Model	YN-DTF-1200Z
working space	φ1200×1100mm
working pressure	0.85MPa
working temperature	185ºC
Design pressure	0.95MPa
Voltage regulating range	0~0.85MPa
Boost rate	0.6MPa/5s
power	380V/50Hz 153kw
dimensions	4250×2050×2150
weight	4.2T

2,Description

The DTF electrically heated steam dewaxing kettle is a core component of our comprehensive precision Casting Equipment line, specifically designed to optimize the dewaxing process for medium-sized investment casting shells. Incorporating cutting-edge domestic and international design and manufacturing technologies, this advanced system offers safety, reliability, and practicality, with rapid heating and efficient dewaxing operations. As a leading solution in its field, it stands out for its exceptional environmental performance and superior thermal efficiency, making it the preferred dewaxing equipment for ensuring operational excellence and sustainable production standards.
3,Main Features and Advantages

3.1The DTF electric steam dewaxing kettle incorporates an advanced double-layer pressure vessel design that delivers exceptional performance through its innovative thermal management system. During operation, the outer tank maintains high-temperature and high-pressure conditions, ensuring the inner surface consistently remains above 150°C to prevent any condensation formation while achieving rapid thermal equilibrium. This optimized heat transfer mechanism significantly reduces high-temperature steam consumption during the dewaxing process, while simultaneously preventing shell cracking and maintaining exceptionally low wax moisture content for superior casting quality. The system's intelligent design combines energy efficiency with reliable operation, making it an ideal solution for precision dewaxing applications.
3.2 The electric heating dewaxing kettle features a robust structural design comprising a tank body mounted on a sturdy base, integrated with a quick-opening door mechanism for efficient operation. The complete system includes a dedicated wax bath, high-performance heating elements, and a sophisticated electrical control cabinet housed within a protective outer skin. For enhanced operational efficiency, the unit incorporates a specialized carriage system designed for smooth transportation of mold shells and baskets during the dewaxing process.

Engineered for both safety and convenience, the quick-opening door mechanism significantly reduces operational time while maintaining high safety standards through an integrated interlock system that prevents door opening when the exhaust valve remains closed. The equipment offers precise pressure control within its design parameters, allowing users to adjust operating pressure according to specific process requirements. Advanced safety features include automatic heating cut-off protection that activates when water levels fall below predetermined limits, preventing heater damage from dry firing, along with a temperature monitoring system that triggers alarms and heating termination when exceeding preset thresholds.

The comprehensive safety and control package includes a full complement of valves (safety, intake, exhaust, wax, drain, and check valves), pipeline filtration, and precision instrumentation (pressure and temperature gauges), ensuring reliable and controlled dewaxing operations. This integrated design approach combines operational efficiency with multiple layers of safety protection for optimal performance in precision casting applications.

Supply Ability & Additional Information

Packaging: WOODEN BOX

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 120PIECES/YEAR

Certificate: ISO 9001:2015

Port: QINGDAO

Payment Type: T/T

Incoterm: FOB,CIF,EXW
